OVERVIEW

What is NEXT ?

Introducing the Next Generation Smart Cabin Router (NEXT) – the cutting-edge security platform that provides the ultimate connectivity flexibility for your business jet cabin. Our innovative solution ensures that you stay connected and protected against cyber threats, giving you peace of mind as you soar through the skies.

With NEXT, your avionics network is secured with the highest level of protection, thanks to our state-of-the-art features. Our fully-featured security platform is designed to safeguard your data, offering top-of-the-line security features that give you unparalleled protection.

But that’s not all – the NEXT solution is satellite-ready and supports seamless communication for L-Band, Ku-Band, Ka-Band, X-Band, and ATG. Stay connected to the world no matter where your travels take you.

Experience the ultimate in avionics network security with NEXT – the smart choice for owners, operators, passengers, and crew. Upgrade to NEXT today and discover the power of ultimate flexibility and security in connectivity for your business jet cabin.

_

DO-160G

Qualified

_

DO-178C

Compliant

_

KONTRON

Hardware Partner

VERSATILE – FULLY FEATURED

  • Multi-WAN Load Balancing & BONDING
  • Multiple SSID with 2.4GHz and 5GHz
  • Least Cost & Policy Based Routing (LCR & PBR)
  • Intelligent QoS & Extensive Bandwidth Management
  • Stateful Firewall and IPS/IDS
  • Built-in Cabin PBX including AMBE+2 Call Support
  • Real-time Monitoring using iOp/AeroSphere Suite
  • High Availability (VRRP)
  • A429 and I/O Discrete Support
_

COMPATIBLEAVIATION NETWORK

HARDWARE SPEC

ROUTER SPECIFICATION


Avionics Certified – Ultra Small – Secure Gateway Router

  • FORM FACTORSmall Form Factor: 1.75”H x 7.8”W x 5.5”D; conduction cooled
  • PROCESSORIntel® E3845, 4-Core Processor, 1.5 GHz
  • DRAM4 GByte ECC RAM
  • OPERATING SYSTEMLinux Debian 9
  • SECURITYTPM 1.2 On board
  • WEIGHT3.4 lbs (1.5 kg) with cellular modem
    3.9 lbs (1.7 kg) with cellular and WiFi modem
  • STORAGE64 GByte eMMC fixed storage (OS & Router Software)
  • ETHERNET PORTS5x 10/1000/1000BT Ethernet Ports (Switched) via J2, J3 & J4 rear connectors
    1x 10/1000/1000BT Ethernet Port (Direct) via J2 rear connector
    1x 10/1000/1000BT Ethernet Port RJ45 front access panel
  • ETHERNET SWITCHL2 Managed Ethernet Switch
  • ARINC 429Two (2) Rx Channels (fixed), One (1) Tx Channel (fixed)
  • AIRCRAFT DISCRETES 4x Inputs/ 2x Outputs (ESD/opto-isolated) via J1 rear connector
  • ISDN BRI1x ISDN Channel 2B+D
  • CELLULAR MODEM4G/LTE Advanced+ modem for global coverage
    Dual Mini SIM access via front access panel
    2x RF QMA connections via front panel (Diversity)
  • WiFi802.11 ac/abgn WiFi radio with 3x external RF QMA connections via front panel
  • USB1x USB 2.0 via J1 connector
    1x USB 2.0 via front access panel
  • Video1x mini Display Port via front access panel
  • SERIAL1x RS232 (mini USB Type B) via front access panel
  • POWER28 VDC with 200 msec Hold-up
    20 W (nominal)
